CNC- 150 Centerless Grinding Machinery

CNC- 150 Centerless Grinding Machinery
CNC- 150 Centerless Grinding Machinery
Product Code : CNC- 150
Brand Name : BHAGWANSONS
Product Description

CNC- 150 Centerless Grinding Machinery

With the help of our manufacturing unit & experienced personnel, our company brings forth an exclusive range of CNC- 150 Centerless Grinding Machinery Air cooler, high efficiency and durability add an advantage to our range of grinding machine. We assure our esteemed clients that the offered grinding machines are precisely engineered as per international standards using top notch quality of raw materials. Further, this CNC- 150 Centerless Grinding Machinery is available for respected clients in the market at cost effective prices.

Salient Features:

  • Rigid, stable and naturally seasoned Meehanite casting machine bed
  • Precision Guide ways and ball screws for each CNC axis
  • Grinding wheel head with hydrodynamic/roller bearings and with constant peripheral speed
  • Regulating wheel head with precision bush/roller bearings and with VFD/servo drive
  • Air cooler for hydraulic oil
  • Highly accurate CNC profile dressing slides
  • Swift, easy set up and wheel change over
  • Eco friendly, easy to operate, ergonomically designed to fit today's requirement of quality, precision and production
  • Available from single axis to six axes

Technical Specifications:


CNC-100

CNC-150

CNC-200

CNC-250

Grinding Capacity

Diameter (mm)

1-75

1-100

2-125

2-125

Width (mm)

100

150

200

250

Grinding Wheel

Dimension (mm)

350

400

500

500

Width (mm)

100

150

200

254

Bore (mm)

152

203.2

304.8

304.8

Speed with VFD

33m/s

33m/s

33m/s

33m/s

Regulating Wheel

Diameter (mm)

225

250

300

305

Width (mm)

100

150

200

254

Bore (mm)

76

110

127

127

Speed R.P.M.GM 01

V.F.D.

20-250

20-250

15-250

15-250

Servo Drive

15-300

15-300

10-300

10-300

Tilting Angle

+ 5o

+ 5o

+ 6o

+ 6o


-3o

-3 o

-3 o

-3 o

Swiveling Angle

0o

+1o

+1o

+1o

Power requirements AC 415V, 3 phase, 50 Hz

Grinding Wheel Motor

7.5 KW

7.5 KW

15.0 KW

18.75 KW

Regulating Wheel Motor

1.5 KW

1.5 KW

2.2 KW

2.2 KW

Coolant Pump Motor

0.12 KW

0.18 KW

0.37 KW

0.37 KW

Lubrication Pump

0.18 KW

0.18 KW

0.18 KW

0.18 KW

Hydraulic Unit Motor

0.75 KW

0.75 KW

0.75 KW

0.75 KW

Dimensions & Weight

Length (mm)

2350

2410

3010

3010

Width (mm)

1320

1360

1700

1750

Height (mm)

1650

1655

1900

1900

Net Weight Approx (Kgs)

1900

2400

5000

5300

Standard Accessories

  • Controller, Grinding wheel with flange
  • Regulating wheel with flange, Coolant pump with tank
  • Hydraulic tank with pump, Work rest blade for through feed grinding
  • Motorized centralized lubrication for slides
  • Machine lamp, Splash guards
  • A.C drive for grinding wheel head
  • A.C. drive for regulating wheel head
  • Instruction manual, Tool kit
  • Micro feed fine adjustment for depth of cut
  • Template truing slides for profile dressing
  • Hydrodynamic bush bearing for GW head( only in 250)
  • Bush bearing for RW head ( only for 250)
  • Hydraulic oil cooler

Optional Accessories

  • Servo control voltage stabilizer
  • Fully enclosed splash guards
  • Hydrodynamic bush bearings for GW head except 250
  • Bush bearing for RW head except 250
  • Wheel balancing stand with arbor
  • Additional grinding wheel flange
  • Additional regulating wheel flange
  • Additional work rest blade through feed
  • Additional work rest blade infeed
  • Magnetic coolant separator
  • Paper cum magnetic coolant separator
  • Anti vibration pads
  • Profile templates
  • Servo drive motor for regulating wheel
  • Vibratory bowl feeder
  • Bar feeder for long bar grinding
  • Auto infeed grinding with hydraulic cylinder
  • Auto ejector for infeed grinding hydraulic
  • Auto ejector for infeed grinding pneumatic
  • Auto lifter for infeed grinding
  • Auto loading attachment for infeed
  • Automatic feeder for through feed grinding
  • Automatic balancing for grinding wheel
