Hydraulic Centerless Grinder - HCG 250

Hydraulic Centerless Grinder - HCG 250
Hydraulic Centerless Grinder - HCG 250
Product Code : HCG 250
Brand Name : BHAGWANSONS
Product Description

Hydraulic Centerless Grinder - HCG 250

Our company has been able to mark its strong presence in the market as one of the well established manufacturers and exporters of Hydraulic Centerless Grinder - HCG 250. Clients are appreciating our offered variety of grinders due to its salient features like low maintenance cost, smooth operation and durability. Our manufactured grinders are exported to the other countries such as Turkey, Kenya, China, Oman and Germany. The offered range of Hydraulic Centerless Grinder - HCG 250 is highly used by many industries for grinding operations.

Salient Features:

  • Designed for both through-feed & in-feed grinding
  • Microfeed-fine adjustment for depth of cut
  • Minor taper adjustment without dressing except in HCG-100
  • Template truing devices fitted with linear slides, optional in HCG-100
  • Grinding wheel & regulating wheel head fitted with precision roller/hydrodynamic bearings
  • Regulating wheel variable speed drive in HCG - 250/200, optional in HCG - 150/100
  • Separate motorized lubrication system for grinding wheel head with safety float switch
  • Precision ball screw for depth of cut in HCG - 250/200, optional in HCG - 150/100
  • Dressing slides hardened ground and protected with way wipers
  • Grinding wheel duly balanced and easy to load and unload
  • Apart from above, machines are compact, rigid and stable in design

Technical Specifications

Capacity

HCG-250

Max. opening between new wheels mm Max. width in infeed grinding mm

2-125 250

Grinding Wheel

500x254x304.8 1270

Dimension O.D. x width x I.D. mm Speed RPM


Regulating wheel

305x254x127
15-200
+6
o/-3o
+1o

Dimension O.D. x width x I.D. mm Stepless variable speed rpm Tilting Angle Swivelling Angle


Power requirement

18.75 KW 1.5 KW 0.37 KW 0.18 KW 0.75 KW

Grinding wheel motor Regulating wheel motor Coolant pump motor Lubrication pump Hydraulic unit motor


Dimension & Weight

1055 mm 2840 x 1670 x 1650 mm 4200 kg

Height from floor to wheel center Length x Width x Height Net Weight (Approx.)


Standard Accessories

  • Grinding wheel with flange
  • Regulating wheel with flange
  • Coolant pump with tank
  • Hydraulic tank with pump
  • Work rest blade for through feed grinding
  • Hand pump lubrication for slides
  • Machine lamp,Splash guards
  • A.C. drive for regulating wheel head
  • Instruction manual,Tool kit
  • Micro feed fine adjustment for depth of cut
  • Template truing slides for profile dressing
  • Hydrodynamic bush bearing for GW head
  • Bush bearing for RW head
Optional Accessories
  • Motorized centralized lubrication for slides
  • Fully enclosed splash guards
  • A.C. drive for grinding wheel head
  • Wheel balancing stand with arbor
  • Additional grinding wheel flange
  • Additional regulating wheel flange
  • Additional work rest blade through feed
  • Additional work rest blade infeed
  • Magnetic coolant separator
  • Paper cum magnetic coolant separator
  • Anti vibration pads,Hydraulic oil cooler
  • Profile templates,Vibratory bowl feeder
  • Bar feeder for long bar grinding
  • Auto infeed grinding with hydraulic cylinder
  • Auto ejector for infeed grinding hydraulic
  • Auto ejector for infeed grinding pneumatic
  • Auto lifter for infeed grinsing
  • Auto loading attachment for infeed
  • Automatic feeder for through feed grinding
  • Automatic balancing for grinding wheel
